TCR Series
High Frequency Online UPS
1Phase Input/1Phase Output
1 – 10 kVA
Product
TCR11 series is online double-conversion UPS with full DSP control technology. With 19 inch standard rack design, self-adjusting output frequency, smart battery management system and network management. TCR11 is a perfect choice for computers, IT equipment and other sensitive device.
DSP Technology
The advanced DSP digital control technology enables UPS more stable performance.
Active input power factor correction (PFC)
Digitalized control of the PFC enable the UPS to keep input power factor above 0.99 to prevent possible electric grid pollution and meanwhile mostly save the cost.
Zero power switch delay
When the utility power fails, UPS will automatically switch from AC mode to battery mode with no delay, which ensures stable power supply of operating system.
Environment Friendly
This UPS is eco-designed and manufactured to meet the most local pollution control requirement of Electronic Products, which means it will cause no harm to environment and human beings in normal usage.
Wide range of input voltage and frequency
We intentionally widen the range of input factors to make sure the UPS can apply to various environment, which will effectively sustain the battery charging even in unstable power environment so that the service life of the UPS could be obviously prolonged.
Application
IDC (Internet Dater Center) network, servers and workstations, control system, communication system, office, PC etc.
Features:
- True online double-conversion technology
- Wide input voltage range and stable power supply extends battery lifetime
- DSP technology
- Advanced PFC technology, input PF>99%
- Cold start
- Automatic battery charging on/off mode
- Lighting and surge protection
- LCD
- Smart RS232 port with monitoring software
- Smart slot for mission critical applicationsTCR11 Series 1kVA~10kVA Online Double Conversion 19″ rackmount or Tower UPS
