CX Series (100 ~ 1200kVA)
Modular UPS (100k module)
Introduction
CX 100-1200kVA is the newest generation of centralized bypass three-in-three-out modular UPS. The product adopts digital control, modular design and N+X parallel redundancy technology. The capacity covers all power sections between 100kVA and 1200kVA, which is convenient for users to configure flexibly and gradually invest. It can be 4 parallel to 4800kVA.
Applications
Large and medium centers, server rooms, financial centers, government, enterprise IT rooms, medical education and other mission-critical applications.
Features
Advance Technology
- DSP control technology, excellent
performance, high stability system
- Three phase Vienna and three-level technology with more than 96% efficiency
- Output power factor 1.0
High Reliability
- Output Centralized control redundancy, N+X
- Parallel redundancy up to 99.999%
- Centralized bypass improves the power supply ability
- With EPO and REPO function
Strong Convenience
- Modular design, adjustable power module quantity
- Hot-swappable module, short maintenance time
10 inches color touch screen, providing abundant UPS status
Smart Design
- Charging mode in smooth switching by LCD setting
- Intelligent charging makes fast charging and extends battery life
- Multiple optional parts, such as SNMP, relay, dry contact card, etc
Green Concept
- 3U modular design saves machine room’s space
- Parallel shared battery technology reduces battery investment
- Optional 30-50pcs batteries without N line leads flexible configuration
