Features
Technical Specification
Features
CX Series (40 ~ 640kVA)
Modular UPS (40k module)
Introduction
CX 40-640kVA is a new generation three-in-three-out modular UPS launched by our company. The products adopt digital control, modular design and N+X parallel redundancy technology, which integrates the most advanced technical achievements in the field of power electronics andautomatic control. It is bench marking product in themodular UPS field. The capacity covers all power sections between 40kVA and 640kVA, which is convenient for users to configure flexibly and gradually invest. It can be 4 parallel to 2560kVA.
Applications
Medium data centers, server rooms Telecom, IT equipment, group enterprises, and other mission critical applications.
Benefits
- Modular design, improves maintainability and reliability
- ECO mode operation for energy saving
- Cold start for easy operation
- Communications for network management and remote monitoring
- N+X redundancy, expanding as required, saves initial investment
Features
- Centralized bypass, centralized control, modular design
- Online double conversion and three level technology
- DSP digital control technology
- Wide input voltage range
- Output power factor 1
- High power density with size
- 440mm*620mm*2U
- Cold start (battery start up)
- ECO mode operation
- Intelligent battery management
- N+X redundancy
- Communications: RS485/Dry contact
- Card/SNMP option
- Optional emergency power off (EPO) function
- Compatible with lithium battery applications
Technical Specification
