RMDi
50 ~ 800kVA
Modular UPS (50k module)
Introduction
RMDi 50-800kVA is a new generation three-in-three-out
modular UPS launched by our company. The products
adopt digital control, modular design and N+X parallel
redundancy technology,
which integrates the most advanced technical
achievements in the field of power electronics and
automatic control. It is benchmarking product in the
modular UPS field. The capacity covers
all power sections between 50kVA and 800kVA, which
is
convenient for users to configure flexibly and
gradually invest. It can be 4 parallel to 3200kVA.
Features
• Centralized bypass, centralized control,
modular design
• Online double conversion and three level
technology
• DSP digital control technology
• Wide input voltage range
• Output power factor 1
• High power density with size
440mm*620mm*2U
• Cold start (battery start up)
• ECO mode operation
• Intelligent battery management
• N+X redundancy
• Communications:
card/SNMP option
• Optional emergency power off (EPO) function
• Compatible with lithium battery applications
