TCA Series
10~60 kVA 3 phases Rack UPS
Features
• IGBT Technology Rectifier & Inverter
• Compatible 3/3, 3/1 and 1/1 operation mode.
• 100,000 history logs for historical performance and event tracking
• With parallel function, up to 3+1 parallel redundant power supply.
• Efficiency: Industry TOP efficiency up to 96%
• 3U (10–30kVA), 4U (40kVA), 7U (60kVA) – space efficient design
• 7-inch LCD screen User-friendly interface to
monitor system status easily
• Supports flexible battery setups to match backup needs (adjustable 32 – 44)
• Fully digital and intelligent battery management function to extend battery life.
• Fan failure self-check and automatic identification functions.
• Provide EPO interface, realize remote shutdown function, make operation more convenient.
• Using DSP full digital control technology, Highly stable system with self-protection and fault diagnostics.
• Standard with RS232 port, USB, RS485 port, cold start, dry contact and Optional with LBS, parallel card, SNMP card.
